SKD61 Hot-work mould steel,tool steel

Product description: SKD61 has good toughness and high-temperature fatigue resistance and can withstand temperature fusion. It is suitable for long-term operation at high temperature with good cutting and polishing performance.SKD61 smelting by the electric furnace and electro slag remelting the steel is purer and more ductile. Suitable for making aluminum, zinc, copper alloy extrusion die, die casting die, hot forging dies, hot shearing blade and other small sizes Yin Liang steel (peeling, cold drawing) materials, is the ideal material for making ejector bar and barrelSimilar GradeExecution standardZEICIN GradeGBAISIDINASSABJIS/ DAIDOGB/T 119.2-2000SKD614Cr5MoSiV1H13X40CrMoV5-1(1.2344)– SKD61Main chemical composition %CCrMnSiMoV0.32~0.424.50~5.50≤0.500.8~1.21.00~1.500.8~1.2CoSPNiNbW–≤0.03≤0.03–––
Product type:
Characteristic:
Description:

SKD61 hot die steel has beautiful metal luster, vacuum degassing refining treatment, pure steel, spheroidizing annealing softening treatment, good cutting performance.Reinforced elements vanadium, molybdenum special addition, excellent wear resistance.






SKD61 hot die steel has beautiful metal luster, vacuum degassing refining treatment, pure steel, spheroidizing annealing softening treatment, good cutting performance.Reinforced elements vanadium, molybdenum special addition, excellent wear resistance.


SKD61 hot die steel has beautiful metal luster, vacuum degassing refining treatment, pure steel, spheroidizing annealing softening treatment, good cutting performance.Reinforced elements vanadium, molybdenum special addition, excellent wear resistance.


Product Details:

SKD61 has good toughness and high-temperature fatigue resistance and can withstand temperature fusion. It is suitable for long-term operation at high temperature with good cutting and polishing performance.SKD61 smelting by the electric furnace and electro slag remelting the steel is purer and more ductile. Suitable for making aluminum, zinc, copper alloy extrusion die, die casting die, hot forging dies, hot shearing blade and other small sizes Yin Liang steel (peeling, cold drawing) materials, is the ideal material for making ejector bar and barrel

Similar Grade

Execution standardZEICIN GradeGBAISIDINASSABJIS/ DAIDO
GB/T 119.2-2000SKD614Cr5MoSiV1H13X40CrMoV5-1(1.2344) SKD61

Main chemical composition %

CCrMnSiMoV
0.32~0.424.50~5.50≤0.500.8~1.21.00~1.500.8~1.2
CoSPNiNbW
≤0.03≤0.03
